Please see here about the isovolta Insulating material.
POROBAND® and POR®Porous mica paper tapes with low resin content having a glass cloth (POROBAND) or film (POROFOL) carrier for continuous main insulation up to the highest voltages |
POROBAND 0410Standard type with uncalcined muscovite mica paper |
POROBAND ME 2072With added accelerator for epoxy resin-anhydride systems |
POROBAND ME 2599As ME 2072, for highest insulation thicknesses and rated voltages |
POROBAND SI 2420With calcined mica paper reinforced by Aramid fibres for silicone-based systems |
POROBAND SI 0790With calcined mica paper reinforced by Aramid fibres for silicone-based systems |
POROBAND SI 2577Consists of calcined muscovite mica paper with Aramidofibre content on glass cloth as carrier.A modified silicone resin is used as binder.Thermal Class C(240℃), for insulation of coils or bars of traction machines. |
POROFOL 2076Standard type with uncalcined mica paper and PET film |
POROFOL ME 2075With added accelerator for epoxy resin-anhydride system |
POROFOL SR 0554As 2076, with thermo-shrinking PET carrier |
POROFOL 0546As 2076, with additional PET fleece cover on one side |
ISOSEAL MF 0611Thermo-shrinking glass/PET film tape, used as final layer,red-brown colour |
POROMATExpandable porous epoxy laminate, used as interlayer, spacer and filling material |
POROMAT 2248Expandable prous epoxy glass mat, both sides covered with PET fleece, as intelayer,spacer and filling material |
POROMAT ME 2242As 2248, but contains accelerator for epoxy resin-anhydride systems, for highest mechanical stress |
POROFILZ 2074Highly absorbent and soft PET felt, contains accelerator, for use as spacer and filling material |
POROFILZ ME 2070Contains accelerator for epoxy resin-anhydride systems |
VOTASTAT VPI-ResinLow-viscosity impregnating epoxy resins for vacuum pressure impregnation of coils and bars as wellas for the global impregnation of high voltage machinees |
VOTASTAT 2010 100/90Expandable prous epoxy glass mat, both sides covered with PET fleece, as intelayer,spacer and filling material |
POROMAT ME 22422-component impregnating resin, consisting of a bisphenol-A epoxy resin and a liquid acid-anhydride hardener with very long pot life and shelf life. Also available readymixed as VOTASTAT VP 1168 |
VOTASTAT 100K/XD4150Solvent-free one-component epoxy resin with a very long pot life |
CONDUCTOFOL®Flexible calcined mica paper tapes with modified epoxy resin(Type K 2011 with silicone resin) on a PET or polyimid film carrier. For single conductor insulation in low- and high-voltage machines |
CONDUCTOFOL 2009Standard type with PET film, Thermal Class F(155℃) |
CONDUCTOFOL 0264As 2009, but coated with a special melting adhesive, Thermal Class F(155℃) |
CONDUCTOFOL 2371With PET film on both sides, Thermal Class F(155℃) |
CONDUCTOFOL 2159As 2371, additionally coated with a special melting adhesive on one side, Thermal Class F(155℃) |
CONDUCTOFOL K 2010With polyimid film for high thermal stress, Thermal Class H(180℃) |
CONDUCTOFOL K 2011With polyimid film and silicone resin for high thermal stress, Thermal Class H(180℃) |
PRINOM E 2084lThermosetting Nomex prepreg, one side coated with modified epoxy resin, Thermal Class H(180℃) |
PRINOM B 2083Thermosetting Nomex prepreg, both sides coated with modified epoxy resin, Thermal Class H(180℃) |
SURITEX®Silicone-fine quality mica paper impregnated with a modified silicone resin on a glass cloth carrier to produce flame-resistant cables that retain function at temperatures above 1000℃ |
SURITEX 0291With calcined muscovite mica |
SURITEX 0822With phlogopyte mica |
SURIFOL®Silicone-fine quality mica impregnated with a modified silicone resin on a PET film carrier to produce flame resistant cables that retain function at temperatures above 1000℃ |
VOTAFIX E 2102Resin-rich epoxy glass cloth prepreg, to preconsolidate highvoltage machine coils |
VOTAFIX TGB 0941Rigid epoxy glass cloth prepreg, to preconsolicate high voltage machine colis |
VOTAFIX NGB 2268As 0941 but with NOMEX® layer, as interlayer under the traspositions in roebel bars |
VOTASTOP 2235Fine mica paper prepreg to fill cavities and as a filler in coils and bars of high voltage machines |
Colona protection and grading tapes |
CONTAVAL 2017Conductive epoxy glass laminate, as slot filler, Thermal Class F(155℃) |
CONTAFEL H 0865Highly flexible, absorbent, conductive PET fleece for corona protection on high voltage coils |
CONTAFEL 2716Conductive PET/glass fabric for corona protection |
CONTAFEL 2995Conductive UD-yarn reinforced PET fleece |
CONTAGLAS 2912Conductive glass cloth for corona protection |
EGSB 2709, 2969Semi conductive thermosetting PET fabric tape as endgrading, for VPI-applications (2709) and RR-applications(2969) |
CALMICA® and CALMICA®SiliconeThermal Class F-H(155℃-180℃), thermosetting materials for main insulations, based on a mica paper fully impregnated with high temperature resistant epoxy resin, on a film (CALMICA) or glasscloth (CALMICAGLAS) carrier |
CALMICA 70 0900PET film carrier with calcined mica, for coils and bars of high volotage machines |
CALMICA 0867PET film carrier with uncalcined mica paper, for coils and bars of high voltage machines |
CALMICA S100 0902Calcined mica paper on PET shrink film carrier, for cols and bars of high voltage machines |
CALMICAGLAS 0893With uncalcined mica, for coils and bars of low- and high-voltage machines |
CALMICAGLAS 2005, 0409With calcined mica, for highest output and voltage |
FEINMICAGLAS®Tapes made of fine mica paper backed with glass cloth (-threads), flexible when fully cured. For insulation of end windings, pole coils and connections |
FEINMICAGLAS 2596Mica and glass cloth carrier |
FEINMICAGLAS 0986With PET film on both sides, also suitable for single conductors and rotor coils of traction motors |
FEINMICAGLAS 2128As 0986, but with unidirectional glass threads as carrier, for overhangs and connections with tight bends |
CALMICA-FLEX®Thermosetting fine quality mica paper glasscloth (-threads), cures to a semiflexible state, for insulation of end windings, pole coils and connections |
CALMICA-FLEX 0917Glass cloth carrier |
CALMICA-FLEX 0919As 0917, but with PET film on both sides |
CALMICA-FLEX 0421As 0919, but with unidirectional glass threads as carrier |
CALMICA-FLEX 0824Glass cloth carrier, PET film on one side, good resistance to humidity and extreme ambient conditions |
CALMICA-FLEX SI 2726Flexible silicone/fine mica paper/glass cloth tape, suitable for the final layer convering on end windings |
ISOSEAL P 0713Red-brown, thermosetting epoxy/PET cloth sealing tape, suitable for the final layer convering on end windings |
